Master unit
|
Low-power embedded industrial computer
|
|
Display mode
|
True color 8.4-inch LCD screen (LED high-light stream backlight)
|
|
Operation method
|
Touch screen operation (USB optional)
|
|
Frequency screen resolution
|
800×600
|
|
Storage method
|
Electronic hard drive / mobile hard drive
|
|
Data backup
|
Automatic or manual
|
|
Storage
|
≤ 10,000 sets of test data
|
|
Input and output interface
|
USB interface / USB HUB / Bluetooth optional
|
|
Number of sampling channels
|
Three lanes / four lanes
|
|
Number of trigger channels
|
One
|
|
Trigger mode
|
External trigger/channel trigger
|
|
Sampling length
|
512、1024、2048、4096（ Ground pulsation measurement samples can be increased by several）
|
|
Sampling interval
|
30μs～65535μs
|
|
A/D conversion
|
24 digits
|
|
Passband
|
0.5Hz～4000Hz
|
|
Trigger delay
|
0～500ms
|
|
Preamplifier
|
10000
|
|
Adjustable magnification
|
1/10/100
|
|
Time indication error
|
≤1%
|
|
System noise voltage
|
≤0.2mV
|
|
Power supply
|
AC / built-in lithium battery
|
|
Host housing
|
High-strength metal engineering chassis
|
|
Operating temperature
|
-10℃～＋50℃
|
